Spesification :
Unique Feature
Superb Productivity
- PCIe Gen5 (Graphics, M.2).
- Dual Channel DDR5.
- Thunderbolt 4 Type-C Ports (40 Gb/s).
Rock-Solid Durability :
- 16+1+1+1+1 Power Phase, Dr. MOS for VCore+GT with Enlarged Heatsink Armor.
- Memory OC Shield.
- Flexible Integrated I/O Shield.
Ultrafast Connectivity.
- 2.5G LAN, 802.11axe Wi-Fi 6E Module.
EZ Update :
- BIOS Flashback Button.
- ASRock Auto Driver Installer.
EZ Troubleshooter.
CPU :
- Supports Intel Core Ultra Processors (Series 2) (LGA1851RL-ILM).
- Supports Intel Hybrid Technology.
- Supports Intel Turbo Boost Max 3.0 Technology.
- Supports Intel Thermal Velocity Boost (TVB).
- Supports Intel Adaptive Boost Technology (ABT).
- Integrated NPU for dedicated AI acceleration.
Chipset :
- Intel Z890.
Memory :
- Dual Channel DDR5 Memory Technology.
- 4 x DDR5 DIMM Slots.
- Supports DDR5 non-ECC, un-buffered memory up to 9066+(OC)*.
- Supports Clocked Unbuffered DIMM (CUDIMM).
- Max. capacity of system memory: 256GB.
- Supports Intel Extreme Memory Profile (XMP) 3.0x.
Slots CPU :
- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*.
Chipset :
- 2 x PCIe 4.0 x4 Slots (PCIE3 and PCIE4), support x4 mode*.
- 1 x PCIe 4.0 x1 Slot (PCIE2)*.
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT).
Storage CPU :
- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*.
- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*.
Chipset :
- 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*.
- 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2230/2242/2260/2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes*.
- 4 x SATA3 6.0 Gb/s Connectors.
USB CPU :
- 2 x Thunderbolt 4 Type-C (Rear).
Chipset :
- 1 x USB 3.2 Gen2x2 Type-C (Front).
- 1 x USB 3.2 Gen2 Type-A (Rear).
- 6 x USB 3.2 Gen1 (2 Rear, 4 Front).
- 8 x USB 2.0 (4 Rear, 4 Front).
Accessories :
- 2 x SATA Data Cables.
- 2 x ASRock WiFi 2.4/5/6 GHz Antennas.
- 1 x Screw for M.2 Socket.
- 1 x Standoff for M.2 Socket.
Form Factor :
- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm.
- 2oz Copper PCB. (CALL FOR STOCK)
