ASROCK MOTHERBOARD B860M PRO RS WIFI - INTEL LGA1851 - B860 - DDR5

Spesification : Unique Feature Superb Productivity - PCIe Gen5 (Graphics, M.2). - Dual Channel DDR5. Rock-Solid Durability : - 10+1+1+1+1 Power Phase, Dr.MOS for VCore+GT+SA+VNNAON. - Pre-Installed I/O Shield. Ultrafast Connectivity : - 2.5G LAN, 802.11axe Wi-Fi 6E Module. EZ Update : - BIOS Flashback Button. - ASRock Auto Driver Installer. EZ Troubleshooter : - ASRock Post Status Checker. CPU : - Supports Intel Core Ultra Processors (Series 2) (LGA1851). - Supports Intel Hybrid Technology. - Supports Intel Turbo Boost Max 3.0 Technology. - Supports Intel Thermal Velocity Boost (TVB). - Supports Intel Adaptive Boost Technology (ABT). - Integrated NPU for dedicated AI acceleration. Chipset : - Intel B860. Memory : - Dual Channel DDR5 Memory Technology. - 4 x DDR5 DIMM Slots. - Supports DDR5 non-ECC, un-buffered memory up to 8666+(OC)*. - Supports Clocked Unbuffered DIMM (CUDIMM). - Max. capacity of system memory: 256GB. - Supports Intel Extreme Memory Profile (XMP) 3.0x. BIOS : - 256Mb AMI UEFI Legal BIOS with GUI support. Graphics : - Intel Xe LPG Graphics Architecture. - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz. - 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz. * Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. Audio. - 7.1 CH HD Audio (Realtek ALC897 Audio Codec). - Nahimic Audio. LAN : - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s. - Dragon RTL8125BG. - Supports Dragon 2.5G LAN Software. - Smart Auto Adjust Bandwidth Control. - Visual User Friendly UI. - Visual Network Usage Statistics. - Optimized Default Setting for Game, Browser, and Streaming Modes. - User Customized Priority Control. Wireless LAN : - 802.11axe Wi-Fi 6E Module. - Supports IEEE 802.11a/b/g/n/ac/ax/axe. - Supports Dual-Band 2x2 with extended 6GHz band* support. - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology. - Supports Bluetooth 5.3. - Supports MU-MIMO. CPU : - 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*. Chipset : - 1 x PCIe 4.0 x4 Slot (PCIE2), supports x4 mode*. - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT). * Supports NVMe SSD as boot disks. Storage CPU : - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*. Chipset : - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2230/2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*. - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*. - 4 x SATA3 6.0 Gb/s Connectors. * Supports Intel Volume Management Device (VMD). Supports NVMe SSD as boot disks. RAID : - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices. USB CPU : - 1 x USB 3.2 Gen2x2 Type-C (Rear). Chipset : - 1 x USB 3.2 Gen1 Type-C (Front). - 7 x USB 3.2 Gen1 Type-A (3 Rear, 4 Front). - 6 x USB 2.0 (2 Rear, 4 Front). * All USB ports support ESD Protection. Connector : - 1 x SPI TPM Header. - 1 x Power LED and Speaker Header. - 1 x RGB LED Header*. - 3 x Addressable LED Headers**. - 2 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)***. - 3 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)***. - 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)***. - 1 x 24 pin ATX Power Connector. - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector). - 1 x 4 pin 12V Power Connector (Hi-Density Power Connector). - 1 x Front Panel Audio Connector. - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports). - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports). - 1 x Front Panel Type C USB 3.2 Gen1 Header. (Call For Stock)

Rp 3.045.000

Stok: 50 tersedia
