Spesification :
Unique Feature
Superb Productivity
- PCIe Gen5 (Graphics, M.2).
- Dual Channel DDR5.
Rock-Solid Durability.
- 10+1+1+1+1 Power Phase, Dr.MOS for VCore+GT.
- Pre-Installed I/O Shield.
Ultrafast Connectivity.
- 2.5G LAN, 802.11axe Wi-Fi 6E Module.
EZ Update.
- BIOS Flashback Button.
- ASRock Auto Driver Installer.
EZ Troubleshooter.
- ASRock Post Status Checker.

CPU :
- Supports Intel Core Ultra Processors (Series 2) (LGA1851).
- Supports Intel Hybrid Technology.
- Supports Intel Turbo Boost Max 3.0 Technology.
- Supports Intel Thermal Velocity Boost (TVB).
- Supports Intel Adaptive Boost Technology (ABT).
- Integrated NPU for dedicated AI acceleration.

Chipset :
- Intel B860.

Memory :
- Dual Channel DDR5 Memory Technology.
- 4 x DDR5 DIMM Slots.
- Supports DDR5 non-ECC, un-buffered memory up to 8666+(OC)*.
- Supports Clocked Unbuffered DIMM (CUDIMM).
- Max. capacity of system memory: 256GB.
- Supports Intel Extreme Memory Profile (XMP) 3.0x.

* 1DPC 1R Up to 8666+ MHz (OC), 5600 MHz Natively. 1DPC 2R Up to 6800+ MHz (OC), 5600 MHz Natively. 2DPC 1R Up to 6533+ MHz (OC), 4800 MHz Natively. 2DPC 2R Up to 5600+ MHz (OC), 4400 MHz Natively.

BIOS :
- 256Mb AMI UEFI Legal BIOS with GUI support.

Graphics :
- Intel Xe LPG Graphics Architecture.
- 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz.
- 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz.

* Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.

Audio :
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec).
- Nahimic Audio.

LAN :
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s.
- Dragon RTL8125BG.
- Supports Dragon 2.5G LAN Software.
- Smart Auto Adjust Bandwidth Control.
- Visual User Friendly UI.
- Visual Network Usage Statistics.
- Optimized Default Setting for Game, Browser, and Streaming Modes.
- User Customized Priority Control.

Slots
CPU :
- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*.
Chipset :
- 1 x PCIe 4.0 x16 Slot (PCIE2), supports x4 mode*.
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT).

* Supports NVMe SSD as boot disks.

Storage
CPU :
- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*.
Chipset :
- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2230/2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*.
- 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*.
- 4 x SATA3 6.0 Gb/s Connectors.

* Supports Intel Volume Management Device (VMD).
Supports NVMe SSD as boot disks.

RAID :
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices. (Call For Stock)
